Product Details
Place of Origin: CHINA
Brand Name: HUAHENG
Model Number: AB-Axis 5-Axis
Document: Product Brochure PDF
Payment & Shipping Terms
Axes Configuration: |
X, Y (Ym/Ys), Z, A, B |
Motion Range: |
Linear Axes: Customizable Travel; A/B: ±180° (typical) |
Drive Type: |
Servo-driven With Closed-loop Feedback |
RTCP Implementation: |
Software Compensation Based On Torch Height |
Control Adjustments: |
Angle Compensation → Size Compensation (sequential Due To Angle-size Dependency) |
Axes Configuration: |
X, Y (Ym/Ys), Z, A, B |
Motion Range: |
Linear Axes: Customizable Travel; A/B: ±180° (typical) |
Drive Type: |
Servo-driven With Closed-loop Feedback |
RTCP Implementation: |
Software Compensation Based On Torch Height |
Control Adjustments: |
Angle Compensation → Size Compensation (sequential Due To Angle-size Dependency) |
| Component | Description |
| Linear Axes | X (horizontal), Y (bilateral drive: Ym + Ys), Z (vertical) |
| Rotational Axes | A (rotation around X-axis), B (rotation around Y-axis) |
| Kinematic Structure | 5-axis simultaneous interpolation (X, Y, Z, A, B) for complex bevel angles. |
| Y-Axis Design | Dual-side driven (Ym + Ys) for enhanced rigidity and synchronization. |
| RTCP Mechanism | Tool Center Point Control relies on torch mounting height; minimal mechanical adjustments required. |
